Basic Info.

Model NO.	HZ-QX-2
Feed Cylinder Structure	Multi-Room Feeding
Packaging	Keg
Packaging Material	Metal
Transport Package	Wooden Case
Origin	Shandong
HS Code	8422200000
Production Capacity	100 Sets Per Year

Product Description

Double Stations Beer Keg Washing MachineMain technical parameters

Equipment Outer Dimensions	120016002000mm
Net Weight	350KG
Power	Steam Heating: 3KW Electric Heating: 18KW
Production Capacity	60-80 kegs/H
Washing Method	Invert Washing
Applicable Kegs	5L-60L
Heating Way	Electric Heating or Steam Heating
Power Supply Voltage	customized

Main function and feature1,All procedures are thoroughly controlled by SIEMENS programmable controller. All parameters (time values) can be adjusted without stopping the machine.2,Two sets of washing process for customers to choose.3,Disinfectant and Caustic could be used repeatedly to save water4,Water tank possess heating function, the temperature can be displayed on screen.5,With steam sterilization function (user-selectable).Working process:With 2 tanks:Start (pressing) --- drain residue --- water washing ---drain -- Caustic washing --recycle--- Hot water washing--drain --- Hot water washing --drain --- Steam sterilization --Co2 purge --- Co 2 pressurization -- StopWith 3 tanks:cylinder pressing→ air blowing (draining residue) → water wash (drain)→ air blowing (drain) → caustic wash → air blowing (caustic recycle) → hot water wash→ air blowing (drain) →hot water wash (drain)→ air blowing (drain) →water wash (drain)→ air blowing (drain) →sanitizer wash (sanitizer recycle)→ air blowing (sanitizer recycle) →water wash (hot water recycle)→ air blowing (hot water recycle)→steam sterilization (drain)→CO2 replace steam (drain)→ water wash ( hot water recycle)→ Co2 blowing (hot water recycle)→CO2 pressurize
